Choosing The Right Rotor And Stator for your Rendering Machine

Choosing The Right Rotor And Stator for your Rendering Machine

Rendering machines come in many shapes and sizes from Diesel machines capable of pumping 100 litres a minute to smaller electric machines perhaps requiring a little more control and therefore a lower output. The rotor and stator mechanism is a key element to consider when planning your project as you will want to match it to your machine, material (aggregate size) and desired pumping speed/pressure. The product spec sheet is your first port of call when it comes to understanding which rotor and stator works for you.

Rendering Machines For Sale

Generally the rotor and stator size reflects the size of your machine. A larger version will cope with bigger aggregate and has a greater material output. The size isn’t only an indicator of the machine size but also enables you to:

Rotor and Stator image

It is not only the size of the rotor and stator that influences the above factors but also the pitch (ridges/grooves on the rotor) and the shore (how soft/firm the stator is). For more information on how rotors and stators vary check out our blog here >

Below you’ll find some guidance on selecting the right rotor and stator for your rendering machine and material choice. Here are three of our popular render machines alongside the parts available for them:

Euromair MixPro 28

The Euromair MixPro 28 is a popular electric machine capable of mixing and pumping various products including roughcast, top coat, basecoat, monocouche and latex screed. The Euromair MixPro 28 is a continuous mixing pump whose pumping capabilities can be adjusted by changing the rotor and stator set up.

Rotor & Stator

Material Output

Used to Pump

Mixer 13

10 litres per minute

Roughcast and Top Coat

Mixer 26 (fitted to new machines)

16 litres per minute

Basecoat and Monocouche

Mixer 32

30 litres per minute

Latex Screed

Euromair MixPro 50

The MixPro 50 is another great option for spraying render. This three-phase continuous mixing pump is compatible with a range of renders including Weber Pral M, Krend K1, Parex Monorex to name a few. The rotor and stator options for this machine include:

Rotor & Stator

Material Output

Used to Pump

D4-3

14 litres per minute

Roughcast

D6-3 (fitted to new machines)

20 litres per minute

Basecoat and Monocouche

D7-2.5

25 litres per minute

Basecoat and Monocouche

D8-2

32 litres per minute

Latex Screed

Euromair X-Pro D80

The Euromair X-Pro D80 is a large diesel machine with much larger pumping capabilities with a 200 litre hopper so suitable for bigger projects. The batch mixer pump and sprayer is designed with a built in compressor and will cope with up to 6mm aggregate material. Here are the range of rotor and stator parts compatible with this machine:

Rotor & Stator

Material Output

Used to Pump

2L6

60 litres per minute

Render & Grout

2L6+++ (fitted to new machines)

100 litres per minute

Render & Grout

Map 9

320 litres per minute

Flow Screed

For more information or advice on your rotor and stator or more general queries with regards to your rendering machine, contact us on 01494 715472.
